12 Port Gigabit Industrial Fiber Switch 10/100 / 1000mbps Managed Switch DC48V
Ask Latest Price
Video Channel
Brand Name :Olycom
Model Number :IM-FP488GW
Certification :CE RoHS FCC ISO9001
Place of Origin :Guangdong, China
MOQ :1 pc
Price :Negotiable
Payment Terms :T/T, PayPal
Supply Ability :5000pcs/month
Delivery Time :3~5 working days
Packaging Details :1pc in a box
Optical Fiber :4 LC Port
Certificaiton :CE FCC ROHS compliance
Surge protection :±6KV
Power input :48 to 52v DC redundant power
Housing :IP40 Protection Grade, DIN Rail Type
more
Contact Now

Add to Cart
Find Similar Videos
Black Case 8 Port Managed POE Af/At/Bt Industrial Ethernet Switch With 2 Combo Ports 01:57
Black Case 8 Port Managed POE Af/At/Bt Industrial Ethernet Switch With 2 Combo Ports
8 Port Ultra PoE VLAN Managed Switch Gigabit Ethernet 802.3bt Compliant 720W Budget 00:38
8 Port Ultra PoE VLAN Managed Switch Gigabit Ethernet 802.3bt Compliant 720W Budget
8 Port Industrial Managed PoE Switch 2.5G Fiber Din Rail 240W Support PoE Management 01:03
8 Port Industrial Managed PoE Switch 2.5G Fiber Din Rail 240W Support PoE Management
15.4W Industrial Managed POE Switch 6 Ports Supporting Poe Gigabit Ethernet 00:48
15.4W Industrial Managed POE Switch 6 Ports Supporting Poe Gigabit Ethernet
IEEE802.3Af/At Manageable Switch Poe 8 Port 00:45
IEEE802.3Af/At Manageable Switch Poe 8 Port
Fanless 4 Port Gigabit Poe Switch , High Poe Smart Managed Switch Outdoor 00:55
Fanless 4 Port Gigabit Poe Switch , High Poe Smart Managed Switch Outdoor
IP40 1000Mbps Fiber Optic Industrial Managed Poe Switch 8 Port With Din Rail 00:50
IP40 1000Mbps Fiber Optic Industrial Managed Poe Switch 8 Port With Din Rail
48VDC 8 Port Network Switch 00:45
48VDC 8 Port Network Switch
4 Port Industrial PoE Switch Gigabit Unmanaged Network 120W Budget Din Rail Active PoE 00:42
4 Port Industrial PoE Switch Gigabit Unmanaged Network 120W Budget Din Rail Active PoE
Solar Power UPS PoE Switch Gigabit Network 120W DC12V/DC24V/DC48V Input Unmanaged 00:42
Solar Power UPS PoE Switch Gigabit Network 120W DC12V/DC24V/DC48V Input Unmanaged
View Product Description

12 Port Gigabit industrial fiber Switch

10/100 / 1000mbps managed switch DC48V Input

Key Features of Industrial poe fiber switch

  • Support cable diagnosis and can locate the fault point
  • Support IEEE802.3az EEE (Energy Efficient Ethernet) Management, optimize power consumption
  • Support STP, RSTP, MSTP, ITU-T G.8032 Ethernet Protection Ring(EPR)
  • Support Qos, transport classification Qos, Cos, bandwidth control (input/output direction), storm suppression ,differentiated services
  • Support IEEE802.1q VLAN,VLAN port ,based Mac VLAN,IP subnet VLAN, Protocol VLAN,VLAN convert, MVR
  • Support dynamic IEEE802.3ad LACP link aggregation, static link aggregation
  • Support IGMP/MLD snooping V1/V2/V3, IGMP filtrating/ modulating, IGMP searching
  • Support IGMP agent report, MLD snooping Safety: based on port and Mac IEEE802.1X, RADIUS, ACL, TACACS+,HTTP/HTTPS, SSL/SSH v2
  • Support Cisco® like CLI, Web management, SNMP v1/v2c/v3, Telnet
  • Support software upgrade via TFTP and HTTP, firmware redundancy prevents upgrade failing
  • Support DHCP client/Relay/Snooping/Snooping option 82/Relay option 82
  • Support RMON, MIB II, mirror image, event log, DNS, NTP/SNTP, IEEE802.1ab LLDP
  • Support IPV6 Telnet server /ICMP v6, SNMP, HTTP, SSH/SSL, NTP/SNTP,TFTP, QoS, ACL.

12 Port Gigabit Industrial Fiber Switch 10/100 / 1000mbps Managed Switch DC48V

Specification of Industrial Full Gigabit Switch

Product Name 10/100/1000Mbps Managed Industrial POE Fiber Switch (4F+8TP)
Model No. IM-FP488GW
Port

4 x 1000Mpbs SFP port

SM:1310nm/1550nm,20Km ;1490nm/1550nm, 40~120Km; MM:1310nm, 2Km; 8x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)
Standard IEEE 802.3, IEEE802.3U, IEEE802.3ab, IEEE802.3z, IEEE802.1d STP, IEEE802.1w RSTP, IEEE802.1s MSTP, ITU-T G.8023 EPR/Y.1344, IEEE802.1Q, IEEE802.1X, IEEE802.3ad, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.1ad, IEEE802.1p, IEEE802.1ab, IEEE802.3az
VLAND ID 4096
Jumbo Frame 9.6KB
MAC Address Table Size 8K
Switching features

Transmission mode:storage and forward

System bandwidth:58Gbps (non-traffic jam)

DRAM size: 128M Flash size: 16M
Packet buffer size: 4Mb
Network media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)

100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m)

SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km
LEDs Power, network, fiber
Power supply

POE power supply input voltage: 48V (max 52V),

Single PoE power supply output power: 15.4W (port 1~8)

(802.3at standards required special instructions)
Environment Working Temp:-40°～ 75°C ; Storage Temp:-40°～ 85°C;Working humidity:10%～90%, non-condensing; Storage humidity:10%～95%, non-condensing
Safety CE Mark ,commercial ; CE/LVD EN60950
Mechanical information

Shell:Corrugated metal shell; Safety class:IP40;

Dimension:158 x 114.8 x 60mm;

Mounting method:Din-rail mounting
Warranty 3 years

Industry Standards:

  • EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A
  • EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3,
  • EN 61000-4-4 (EFT) Level 3, EN 61000-4-5 (Surge) Level 3,
  • EN 61000-4-6 (CS) Level 3, EN 61000-4-8;
  • Traffic Control:NEMA-TS2;
  • Vibration:IEC 60068-2-6;
  • Freefall:IEC 60068-2-32;
  • Shock:IEC 60068-2-27;
  • Rail Traffic:EN 50121-4

12 Port Gigabit Industrial Fiber Switch 10/100 / 1000mbps Managed Switch DC48V

Application

12 Port Gigabit Industrial Fiber Switch 10/100 / 1000mbps Managed Switch DC48V

Packing box of Din rail unmanaged switch

12 Port Gigabit Industrial Fiber Switch 10/100 / 1000mbps Managed Switch DC48V

  1. Put the product in an ESD Bag, then placed in PE foams with outer carton packaging.

  2. The standard packing usually contains a main device, a warranty card and a user manual.
  3. Packing box dimension for 1pc: 23*20.8*8cm
  4. 40pcs in a packing box of 55.5*40*41cm dimension.​
