10/100Mbps 5 Port Industrial Network Switch Hub SC Connector Auto MDI/MDIX
Ask Latest Price
Video Channel
Brand Name :OLYCOM
Model Number :IM-FS140FE/SC
Certification :CE, FCC, RoHS
Place of Origin :Shenzhen, China
MOQ :1
Price :Negotiable
Payment Terms :Western Union, T/T, Paypal, D/P, D/A, L/C, MoneyGram
Supply Ability :600 per month
Delivery Time :3-5 days
Packaging Details :One unit device and one user manual are inside one box , sealed and well protected.
Product Name :10/100Mbps 5 Port Ethernet Switch Hub
Fiber Type :SC Single fiber
Distance :20/40/60/80/100km
Ethernet Port :4* RJ45 Ports
Fiber Port :1* SC Port
Dimension :113.8 x 93 x 34.9mm
more
Contact Now

Add to Cart
Find Similar Videos
Industrial Network Switch with 4 Gigabit Ports and EMC Industrial Grade Design 00:43
Industrial Network Switch with 4 Gigabit Ports and EMC Industrial Grade Design
5 Port Gigabit WEB Managed Switch 100/1000M Network Switch Support RSTP 802.1Q 00:20
5 Port Gigabit WEB Managed Switch 100/1000M Network Switch Support RSTP 802.1Q
5-Port Industrial Unmanaged Gigabit Ethernet DIN-Rail Switch -40° – 75°C (-40° – 167°F) 00:32
5-Port Industrial Unmanaged Gigabit Ethernet DIN-Rail Switch -40° – 75°C (-40° – 167°F)
Outdoor Use Switch Fiber Optic 6 Port , Auto MDI/MDIX Industrial Unmanaged Switch 00:50
Outdoor Use Switch Fiber Optic 6 Port , Auto MDI/MDIX Industrial Unmanaged Switch
10/100/1000Mbps Industrial Gigabit Network Switch With Two Fiber Port And Four RJ45 Port 00:44
10/100/1000Mbps Industrial Gigabit Network Switch With Two Fiber Port And Four RJ45 Port
6 Port 40 Gigabit Ethernet Switch Ethernet Rail Switch 9-36VDC Industrial Fiber Switch 00:49
6 Port 40 Gigabit Ethernet Switch Ethernet Rail Switch 9-36VDC Industrial Fiber Switch
10 / 100 / 1000Mbps Six Port Gigabit Industrial Network Switch With FCC CE Standards 00:43
10 / 100 / 1000Mbps Six Port Gigabit Industrial Network Switch With FCC CE Standards
IP44 Industrial Network Switch Ethernet Din Rail Installation 8 RJ45 Ports 00:50
IP44 Industrial Network Switch Ethernet Din Rail Installation 8 RJ45 Ports
OEM Din Mount Ethernet Industrial Network Switch Two 1000M Fiber Port Industrial Fiber Switch 00:32
OEM Din Mount Ethernet Industrial Network Switch Two 1000M Fiber Port Industrial Fiber Switch
Two SFP Port Hardened Network Switch , FCC Certification 6 Port Gigabit Ethernet Switch 00:54
Two SFP Port Hardened Network Switch , FCC Certification 6 Port Gigabit Ethernet Switch
View Product Description

10/100Mbps 5 Port Ethernet Switch Hub SC Connector Single Fiber

Introduction of 10/100Mbps 5 Port Ethernet Switch


IM-FS140FE series is the 10/100 Mbps industrial fiber switch, operating temperature -40 ℃ to + 75 ℃, support wide voltage dual power input, meet IP40 protection degree and EMC industrial grade requirements, DIN rail installation, pass through dangerous environmental certification, and comply with FCC and CE standards. The reliable industrial grade design could ensure continuous and stable operation of the automation system.

Key Features of 10/100Mbps 5 Port Ethernet Switch

  • 4 x 10/100Mbps Auto-sensing RJ45 ports
  • 1 x 100Mbps SFP fiber port
  • 6KV Ethernet surge protection, adapt to a harsh outdoor environment
  • Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Backpressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
  • A store-and-forward switching mechanism
  • Operating environment temperature:-40 ° ~75 ° c

Specification of 10/100Mbps 5 Port Ethernet Switch

Product Name 10/100Mbps 5 Port Ethernet Switch Hub
Model No. IM-FS140FE
Port

1 x 100Mpbs port
SM:1310nm/1550nm,20Km
1490nm/1550nm,40~120Km
MM:1310nm,2Km
4x10/100M UTP RJ45(Support MDI/MDIX auto-sensing)
Switching features

Transmission mode: storage and forward
System bandwidth:40Gbps (non-traffic jam)

DRAM size: 128M
Flash size: 16M
Packet buffer size: 4Mb
Network media

10BASE-T: CAT3, CAT4, CAT5 unshielded twisted pair(≤100m)
100BASE-TX: CAT5 or above shielded twisted pair(≤100m)
SC port,transmission distance: 20Km,40Km,60Km,80Km,100Km
LEDs Power, network, fiber
Power supply

Input voltage:DC 12-52V
No-load power:5W
Reverse connection:support
Environment

Working temperature:-40°～ 75°C
Storage temperature:-40°～ 85°C
Working humidity:10%～90%,non-condensing
Storage humidity:10%～95%,non-condensing
Industry Standards

EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A
EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3,EN 61000-4-8
Traffic Control:NEMA-TS2
Vibration:IEC 60068-2-6
Freefall:IEC 60068-2-32
Shock:IEC 60068-2-27
Rail Traffic:EN 50121-4
Safety

CE Mark, commercial
CE/LVD EN60950
Mechanical information

Shell:Corrugated metal shell
Safety class:IP40
Dimension: 113.8 x 93 x 34.9mm
Mounting method:Din-rail mounting
Warranty 3 years

Packaging & Delivery of 10/100Mbps 5 Port Ethernet Switch

Selling Units: Single item

Single packaging size: 22*16*6cm

Single gross weight: 0.45kg

Package type: One product and one user manual are inside one box

Lead Time: 3-5days and will change according to different quantity


Application of 10/100Mbps 5 Port Ethernet Switch


10/100Mbps 5 Port Industrial Network Switch Hub SC Connector Auto MDI/MDIX
